Heating & Cooling Coils

Name: Heating & Cooling Coils
Brand: Universal Industries
Price: 100000.0 INR
Availability: InStock

Price 100000.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Heating & Cooling Coils Specification

Surface Treatment
Galvanized or Powder Coated

Material
Copper, Aluminum, Stainless Steel

Technique
Fin-and-Tube Construction

Grade
Industrial Grade

Coil Thickness
0.2 mm to 1.2 mm

Coil Weight
Standard/Custom (varies by size and material)

Coil Length
Customizable as per requirement

Hardness
Tempered

Application
HVAC, Air Handling Units, Process Cooling & Heating

Fin Spacing
6 to 13 FPI (Fins Per Inch)

Connection Type
Threaded or Flanged

Temperature Range
-20C to 130C

Fin Material
Aluminum / Copper

Flow Configuration
Counter-Flow / Parallel-Flow

Finish
Anti-corrosive Coating

Leakage Test
100% Factory Tested

Insulation
Optional, as per requirements

Working Pressure
Up to 16 bar

Tube Diameter
9.52 mm, 12.7 mm or customized

Mounting
Horizontal or Vertical

Heating & Cooling Coils Trade Information

Minimum Order Quantity
1 Piece

Delivery Time
5-7 Days

About Heating & Cooling Coils

Heating and cooling coils regulate temperature in conditioned spaces and are commonly integrated into AHUs. Available in multiple configurationsheating coils with 14 rows and cooling coils with up to 12 rowsthey support a variety of working fluids including water, glycols, brines, thermal oils, and specialized heattransfer fluids.

Versatile Design for Multiple Applications

Whether installed in air handling units, process cooling, or heating systems, these coils deliver consistent performance. With customizable lengths and materials, they integrate smoothly into new or existing systems, providing flexibility for diverse HVAC requirements.

Engineered for Durability and Efficiency

Our coils feature tempered materials and high-quality surface treatments-galvanized or powder coated-to prevent corrosion. The anti-corrosive finish and variety of material options ensure a long service life even in demanding environments, while the design maximizes energy efficiency.

FAQ's of Heating & Cooling Coils:

Q: How are the heating and cooling coils customized to fit specific system requirements?

A: These coils can be tailored in terms of tube diameter, coil length, fin spacing, connection type, mounting orientation, and even material composition to meet unique HVAC system demands. Simply provide your required specifications during the ordering process.

Q: What materials are available for the coil fins and tubes, and how do they benefit performance?

A: Fin and tube materials include aluminum, copper, and stainless steel. Aluminum offers excellent thermal transfer and cost efficiency, copper provides superior conductivity, and stainless steel ensures durability in corrosive environments. Choose based on your desired balance of efficiency and longevity.

Q: When should I opt for optional insulation on my coils?

A: Coil insulation is recommended for applications where heat loss or condensation must be minimized, such as in high-humidity areas or systems requiring precise temperature control. The insulation option can be specified as needed.

Q: Where can these coils be installed?

A: These coils are designed for versatile installation, suitable for horizontal or vertical mounting in HVAC systems, air handling units, or process cooling and heating setups commonly found in commercial and industrial facilities.

Q: What is the process to ensure each coil is leak-free and reliable?

A: Every unit is subjected to a stringent, 100% factory leakage test at the rated working pressure, ensuring they meet quality and safety standards before deployment.

Q: How do anti-corrosive coatings and surface treatments benefit the coils?

A: Anti-corrosive coatings, alongside galvanized or powder-coated surface treatments, protect coils against environmental degradation and chemical exposure, thereby extending service lifespan and maintaining high thermal efficiency.
